Front Suspension
|
Arched Double A-Arm, Travel 270mm/254mm
|
||
|
Front Shocks
|
Spiral Spring, Oil Damping Type
|
||
|
Rear Suspension
|
Arched Double A-Arm, Travel 270mm
|
||
|
Rear Shocks
|
Spiral Spring, Oil Damping Type
|
||
|
TIRES/WHEELS
|
|||
|
Front Tires
|
27/30×9/10×14in
|
||
|
Rear Tires
|
27/30×11/10×14in
|
||
|
Wheels
|
14in. Aluminum
|
||
|
Brakes
|
4-Wheel Hydraulic Disc, Rear Wheel Parking
|
||
|
Engine Type
|
4-Stroke DOHC V-Twin, 8 Valves, Liquid-Cooling
|
||
|
Displacement
|
1000cc
|
||
|
Horsepower
|
98hp
|
||
|
Max. Torque (N.m/r/min)
|
92N.m/6500rpm
|
||
|
Fuel System/Cooling
|
EFI/Liquid
|
||
|
Transmission
|
CVT L/H/N/R/P
|
||
|
Drive Train
|
Selectable 2WD/4WD With Diff-Lock
|
||
|
L×W×H
|
3265×1720×2005mm
|
||
|
Bed Box Dimensions
|
1050×1320×280mm
|
||
|
Rear Box Capacity
|
450kg
|
||
|
Wheelbase
|
2060mm
|
||
|
Ground Clearance
|
305mm
|
||
|
Estimated Dry Weight
|
750kg
|
||
|
Towing Capacity
|
1134kg
|
||
|
Fuel Tank Capacity
|
35L
|
||
|
Seat Height
|
510mm
|
||
