Front Suspension
|
Dual A-Arm with sway bar, travel 230mm
|
||
|
Front Shocks
|
Adjustable gas shock absorber
|
||
|
Rear Suspension
|
Independent Torsional Trailing Arm, travel 250mm
|
||
|
Rear Shocks
|
Adjustable gas shock absorber
|
||
|
Front Tires
|
25 × 8 × 12 in & 26 × 9 × 14 in
|
||
|
Rear Tires
|
25 × 10 × 12 in & 26 × 11 x 14 in
|
||
|
Wheels
|
12 in. Aluminum & 14 in. Aluminum
|
||
|
Brakes
|
Dual 220 mm disc brakes
|
||
|
Engine Type
|
4-Stroke SOHC V-Twin Cylinder
|
||
|
Horsepower / Displacement
|
48 HP / 500 CC
|
||
|
Fuel System / Cooling
|
EFI / Liquid
|
||
|
Transmission
|
CVT L / H / N / R / P
|
||
|
Drive Train
|
Selectable 2WD / 4WD with diff-lock
|
||
|
L x W x H
|
2150 × 1250 × 1400 mm
|
||
|
Wheel Base
|
1500 mm
|
||
|
Ground Clearance
|
305 mm
|
||
|
Estimated Dry Weight
|
399 kg
|
||
|
Towing Capacity
|
697 kg
|
||
|
Fuel Tank Capacity
|
30 L
|
||
|
Seat Height
|
95 cm
|
||
