SUSPENSION
|
|||
|
Front Suspension
|
Dual A-Arm With Sway Bar, Travel 230mm
|
||
|
Front Shocks
|
Adjustable Gas Shock Absorber
|
||
|
Rear Suspension
|
Independent Torsional Trailing Arm, Travel 250mm
|
||
|
Rear Shocks
|
Adjustable Gas Shock Absorber
|
||
|
TIRES/WHEELS
|
|||
|
Front Tires
|
30×9-14in
|
||
|
Rear Tires
|
30×11-14in
|
||
|
Wheels
|
14in. Aluminum
|
||
|
Brakes
|
Dual 220mm Disc Brakes
|
||
|
Engine Type
|
4-Stroke SOHC V-Twin Cylinder
|
||
|
Displacement
|
1000cc
|
||
|
Horsepower
|
98hp
|
||
|
Max. Torque (N.m/r/min)
|
92N.m/6500rpm
|
||
|
Fuel System/Cooling
|
EFI/Liquid
|
||
|
Transmission
|
CVT L/H/N/R/P
|
||
|
Drive Train
|
Selectable 2WD/4WD With Diff-Lock
|
||
|
L×W×H
|
2350×1250×1520mm
|
||
|
Wheelbase
|
1500mm
|
||
|
Ground Clearance
|
390mm
|
||
|
Estimated Dry Weight
|
465kg
|
||
|
Towing Capacity
|
792kg
|
||
|
Fuel Tank Capacity
|
30L
|
||
|
Seat Height
|
103cm
|
||
